M588L

M588L Long Time Battery Wireless GPS Tracker

M588L GPS Tracker is used for locating and tracking objects, assets, and other items. It is built-in two strong magnets to make it be adsorbed on the chassis. It not only can be put in objects, but also can be installed on motorcycles, electric vehicles and even bicycles for real time tracking.

Download M588L User Manual

FEATURES

ACCURATE GPS AGPS LBS POSITIONING

Real time GPS location and assisted by AGPS & LBS, the accuracy deviation is less than 5 meters.

RESEND DATA FROM SIGNAL DEAD ZONE

In GSM signal blind areas, the device will store all the GPS data, and resend them immediately to the server in the case of signal recovery.

LONG TIME BATTERY

Big capacity of battery ensures long working time and standby time.

HISTORY PLAYBACK

Check the history location to know where the electric car/motorbike went.

TRACK LOCATION BY WEB, APP, SMS

Three methods help you to know the car location whenever and wherever.

SMS CONFIGURATION

Configure the device by SMS even you are staying thousands of miles away.

IPX5 WATER PROOF

Waterproof feature ensures the device work well under unexpected environment.

MULTIPLE ALERTS

Instant alert for low power, overspeed, geo-fence.

APPLICATIONS

SPECIFICATIONS

Items  Parameters
GSM Module Quectel M35
GSM Frequency 850/900/1800/1900 MHZ
LBS Positioning Accuracy 100-500m
3G Antenna Built-in
GPS Chipset U-blox 7020
GPS Sensitivity -159 dBm
GPS Frequency L1, 1575.42 MHZ
Channels 20 channels examine track
GPS Positioning Accuracy 5-10m, 2D RMS
GPS Antenna Built-in
Speed Accuracy 0.1m/s
Time Accuracy Synchronize with GPS
GPS Data WGS-84
Hot Start <1s
Warm Start <38s
Max Altitude 18000m
Max Speed 515m/s
Gravity Acceleration <4g
Working Current 50Ma~160Ma
Operating Temperature -20℃—70℃
Humidity 5%—95%
Size 125mm ×81mm × 53mm
Simcard Normal simcard
Battery Rechargeable lithium polymer battery 20000mAh
Internal battery Standby >1year

ACCESSORIES

Standard Accessories    USB Charging Cable

Optional Accessories    None

CERTIFICATES

CE, RoHS, FCC
