R14
the Pet GPS Tracker
R14 is a small GPS tracking device for pets. This device weighs only 29g, which is suitable for pets wearing. With built-in 800 mAh battery, it works for 5 days and standby for 15 days.
FEATURES
GPS AGPS LBS WIFI POSITION
GPS real time tracking at interval of 60s. A-GPS for fast locating from satellites. LBS and WiFi for accurate indoor positioning.
SOS CALL AND ALERT
Once the SOS button is pressed, the watch will call the phone numbers in family list and trigger an SOS alert.
VOICE MONITORING
Enable voice monitoring for special situation.
800MA SAFE POLYMER BATTERY
5 working day and 15 days standby.
SAFE ZONE ALERT
Be able to set 10 safe zones for entering and leaving area alert.
HISTORY PLAYBACK
Check the places where the wearer has been to.
APPLICATIONS
SPECIFICATIONS
| Items | Parameters |
| GSM Chipset | MTK 6261 |
| GSM Frequency | 850/900/1800/1900 MHZ |
| LBS Positioning Accuracy | 100-500m |
| GSM Antenna | Built-in |
| GPS Chipset | U-blox 7020 |
| GPS Sensitivity | -163 dBm |
| GPS Positioning Accuracy | 5-25m |
| GPS Antenna | Built-in |
| Wifi Chipset | MT 5931 |
| Wifi Positioning Accuracy | 5-25m |
| Wifi Antenna | Built-in |
| G-Sensor | BOSCH BMA223 |
| Speed Accuracy | 0.1m/s |
| Time Accuracy | Synchronize with GPS |
| GPS Data | WGS-84 |
| Hot Start | <1s |
| Warm Start | <38s |
| Max Altitude | 18000m |
| Max Speed | 515m/s |
| Gravity Acceleration | <4g |
| Operating Temperature | -20℃—65℃ |
| Humidity | 5%—95% |
| Size | 49*49*5 mm |
| Simcard | Micro simcard |
| Battery | Rechargeable lithium polymer battery 800mAh |
| Power Supply | 3.7V-5V, 0.2A-0.5A |
| Standby | >70h |
ACCESSORIES
Standard Accessories USB Charging Cable
Optional Accessories None
